IP67 High Performance LED Fire Truck Scene Light
MODEL: JR605
POWER: 350W 400W 500W 700W 1000W
Input Volt.: AC100-277V
Light effect: 160/170Lm/W
Beam Angle: 4080
Color temperature: 3000-6000K
CERTIFICATION: CE/ROHS/IP67/IK09/ISO9001/ISO14001
- Product Description
- Product Features
- Product Details
- Specification
- Photometrics
- Video
- Application Scenarios
- FAQ
- Send Inquiry
- More Products
Product Description
The floodlight adopts a modular design that allows for free expansion, which significantly increases product adaptability and maintenance efficiency while reducing maintenance costs.
Adapts to the global wide-voltage range of 100~277V for operation and conforms to the voltage standards of various countries, preventing damage caused by voltage fluctuations. The circuit design complies with EMC standards.
There is a wide operating temperature range (-40°C~+60°C), capable of adapting to extremely cold or hot environments.
Product Features
- The floodlight adopts a modular design that allows for free expansion, which significantly increases product adaptability and maintenance efficiency while reducing maintenance costs.
- Adapts to the global wide-voltage range of 100~277V for operation and conforms to the voltage standards of various countries, preventing damage caused by voltage fluctuations. The circuit design complies with EMC standards.
- There is a wide operating temperature range (-40°C~+60°C), capable of adapting to extremely cold or hot environments.
- The floodlight adopts a modular design that allows for free expansion, which significantly increases product adaptability and maintenance efficiency while reducing maintenance costs;
- High-reliability sealed structure design, with a protection level of up to lP67, which is capable of operating in severe weather conditions such as rainstorms and sandstorms.
- Suitable for use on medium-sized special vehicles such as communication command vehicles, lighting vehicles, rescue vehicles, and fire trucks.
Product Details
Adapt to working under adverse weather conditions such as heavy rain and sandstorms
High-reliability sealed structure design, with a protection level of up to lP67, which is capable of operating in severe weather conditions such as rainstorms and sandstorms.
Suitable for medium-sized special vehicles
Professional heat radiation structure, full structure cooling technology, internal and external transparent air duct design, efficient cooling performance.
Modular design
Modular design allows for easy maintenance and meets varying power needs, reducing maintenance costs.
Specification
| Model | Power(W) | Module Qty | Light Efficiency | Voltage(V) | CRI(Ra) | Beam Angle | CCT(K) | Ta | Power Factor | N.W (KG) |
Packing size (mm) |
|
| JR605-350W | 350 | 1 | 160Lm/W | AC100-277V DC48V |
≥70 | 4080 | 3000~6000 | -40~60℃ | ＞0.95 | 5.3 | 306×237×130 | |
| JR605-400W | 400 | 2 | 170Lm/W | 7.3 | 306×353×130 | |||||||
| JR605-500W | 500 | 2 | 160Lm/W | 7.3 | 306×353×130 | |||||||
| JR605-700W | 700 | 3 | 160Lm/W | 10.2 | 306×470×140 | |||||||
| JR605-1000W | 1000 | 3 | 160Lm/W | 16.4 | 612×470×140 | |||||||
| Note: Letter "W" in the model no. stands for AC voltage; "DF" stands for DC48V. | ||||||||||||
Size
| Size/Model | a(mm) | b(mm) | c(mm) |
| JR605-350W | 306 | 237 | 130 |
| JR605-400W | 306 | 353 | 130 |
| JR605-500W | 306 | 353 | 130 |
| JR605-700W | 306 | 470 | 140 |
| JR605-1000W | 612 | 470 | 140 |
Photometrics
Video
Application Scenarios
FAQ
Q: What is the voltage range of your LED flood light fixtures?
A: We offer a voltage range of AC100~277V and DC12V/DC24V/DC48V.
Q: How do your products compare to similar products in the market?
A: Our products are highly efficient, lightweight, anti-corrosive, and anti-shock performance.
Q: What certifications have you obtained?
A: Our LED Lights are CSA, SAA, CE, and BIS-approved.
Q: What's the application for your LED flood Light?
A: Our LED flood lights are widely used at Diesel/Solar/Hybrid lighting towers, stadiums, Sports fields, Ports, Industrial places, Construction Sites, Docks, Mining Sites etc
Q: What's the luminous efficiency of your LED flood light fixtures?
A: Our LED Flood light offers 150~200lm/w.
Q: Do you offer a guarantee for the products?
A: Yes,We offer a 2-year warranty for DC LED lights and a 3-year warranty for AC LED lights(If the generator is used for power generation, the warranty period is 3 years; if used with grid power, the warranty period is 5 years)
Q: Can your factory make the lights based on customers' designs?
A: Yes, we offer OEM and ODM service, we can design and produce according to the client's requests, and we have professional engineers for R&D.
Q: Are you a factory or trading company?
A: We are a factory and trading company integration. our sales center and R&D department are located in Shanghai, and the factory is located in Suzhou City. We welcome customers to visit our factory.
